Patterning Conundrum

Question:

What causes reference patterns to fail by placing the pattern parts coincident with pattern leader? The pattern preview is correct, but when you complete the pattern creation the pattern collapses to the leader location?

Greg Beard (IDE)

Answered by: Gavin B. Rumble, PE Solid Engineering

Greg, Leo described a situation where the constraints for the pattern leader were not properly defined…do you remember what he thought the problem was?

(117)
