Adjusting Sheet Metal Bend K-Factor By Bend

Question:

When working in sheet metal, you can set the k-factor for the entire model.  However when bending a terminal contact, thinning (elongation) occurs.  Can the k-factor be set in a varying factor?

Tim Bolt, Xdin

Answered byBart Brejcha

Yes, you can set the k-factor with respect to each bend feature under the Bend Allowance tab in the feature creation ribbon.

k-factor-by-bend

(536)
